Product application:
Widely used for metal sheet processing, advertising trademark, advertising character, high/low voltage electrical cabinet, mechanism parts, kitchenware, cars, mechanical, metal craftwork, saw blade, electronic parts, eyeglasses, spring, circuit board, kettle, medical microelectronics, hard ware, knives tool, measurement, instrument, etc.
product features:
* High precision cutting
* High speed and efficiency
product details:
|
Model Specifications
|
HN-FL6015
|
|
Fiber Laser Source
|
2000W MAXphotonics
|
|
Effective working length X axis
|
1500mm
|
|
Effective working length Y axis
|
6000mm
|
|
Max cutting thickness
|
MS ≤18mm SS≤8mm
|
|
X,Y Axis positioning accuracy
|
±0.02mm/m
|
|
X,Y Axis repositioning accuracy
|
±0.02mm/m
|
|
X,Y Axis moving speed
|
0-90m/min
|
|
Rated supply voltage
|
380V, 3Phase
|
|
Frequency
|
50Hz
|
|
Power consumption
|
18KW
|
|
General power protection class
|
IP54
|
|
Maximum load of workbench
|
1600KG
|
|
Weight
|
4500KG
|
|
Dimension (Length*Width*Height)
|
7800*2280*1850mm
|
our services
1. We will provide the consumable parts at an agency price.
2. 24 hours online service, free technical support.
3. Machine has been adjusted before delivery, operation disk is included in the delivery. If there is any other questions,
please kindly tell me.
4. We have manual instruction and CD (Guiding Videos) for software Installation, operation and machine's using and maintenance.
