Industrial Radiography Flat Rayos X Ray Flat Panel Veterinary Plate Detector
Product description:
1. Professional pet software workstations, integrated design.
2. The compact structure creates a relaxed surgical environment.
3. Miniature handheld control panel enables surgery more smoothly.
4. Toshiba high-quality image intensifier with the highdense linesfilter grid, contribute to high-quality image acquisition.
5. Self-developed high-frequency mono block, high power output (3.5KW / 5.0KW), no high-voltage c abledesign, beautifulstructure, reliable and practical.
| Item | Technical Data | |
| AC Power | AC 220V+/-10%, 50Hz | |
| Output | Tube current | 5mA |
| High voltage transfer input voltage fluctuation | +/- 1% | |
| X Ray Generator | Cooling method | Force air cooling |
| Insulated method | SF6 gas insulation | |
| Soft working pressure (20ºC) | 0.35~0.45Mpa | |
| Working Condition | Temperature | -30-40ºC |
| Relative Humidity | <85% | |
| Altitude | 1000m | |
| Max Penetration Condition | Steel | A3(mm) |
| Focal length | 600m | |
| Exposure | ≤30mAmin | |
| Film | Double-sided lead foil sensitization | |
| Darkroom treatment | 20+/-2ºC, 5min | |
| Optic density | D≥2.0 | |
| The controller | Size | |
| Weight | ||
| Timing error | 5min +/- 10% | |
| Working Rate | Working & rest 2:1 working rate, the max exposure time 9.5min | |
Stable and reliable:
The product development and production process are strictly controlled in accordance with the ISO9001 quality management system. Through strict high and low temperature tests, electrostatic interference tests, damp heat tests and vibration tests, the products are guaranteed to run continuously for more than 10,000 hours without failure.
Structural design
The frame incorporates advanced industrial design concepts, anti-rust, anti-corrosion, and anti-corrosion cable damage, which is firm and stable
Humanized design Ergonomic design, convenient and comfortable to use; friendly human-computer interaction interface
Easy to maintain, removable protective curtain, easy to clean body design
High-quality belt High-strength polyurethane 1.2mm green food-grade PU belt with better lateral stability
