Truex 960 Handheld Portable X Ray Spectrometer Mineral Ore Gold Testing Machine
Product description:
TrueX 960 Standard configuration mode analysis range, such as special elements, can be added Mg,Al,Si,P,S,Cl,K ,Ca,Ti,V,Cr,Mn,Fe,Co,Ni,Cu,Zn,As,Se,Rb,Sr,Y,Zr,Nb,Mo,Ag,Cd,Sn,Sb,Hf,Ta,W,Au,Hg,Pb,Bi.
Product specification:
|
Weight
|
1.6Kg(with battery).
|
|
Dimensions
|
254 x 79 x 280 mm(L x W x H).
|
|
Excitation source
|
50KV/200μA maximum pipe pressure pipe flow can be adjusted freely,Agtarget (standard),Au,W,Rh target(optional).
|
|
Detector
|
BOOST Si-PIN detector
|
|
Range of detection
|
All elements between Mg and U.
|
|
Display system
|
Industrial resistive touch screen with screen size of 4.3".
Proprietary operating system software and sound waves. Multiple languages including English and Chinese. And it automatically adjusts display brightness according to the environment brightness. |
|
Data processing
|
32GB memory
USB, bluetooth, WIFI, or liked to the Internet; instrument can be configured and repaired remotely. Data can be exported via EXCEL or PDF. Users can customize the reports by adding their company logos, addresses, test results, spectrum and others (such as product description, origin and batch number). |
|
Heat dissipation
|
Equipped with a dedicated T-shaped radiator to dissipate the heat；no need to wait for cooling of detector time again.
|
|
Safety
|
Built-in double beam technology can automatically sense whether
there is a sample at the measurement window. This is also a safety and protection feature. Waterproof, dust-proof and shockproof suitcase Drawell Safety Band； |
|
Power supply system
|
Intelligent battery management through MSBUS bus, real-time
monitoring of the residual capacity of battery and backup battery. The battery complies with air transport regulations of dangerous goods. A single battery can last 8 hours. |
TrueX shows element symbols in both English and Chinese. With high precision, high testing speed and comparable results to even that of laboratory equipment, TrueX displays alloy grade and elements percentage content (up to three decimals) and ppm content in an apparent way.
2. One-touch operation TrueX test lasts only a few seconds and identification of alloy grades takes only 1 or 2 seconds. This facilitates operation by non-technical users.
3. Nondestructive testing (NDT) TrueX test does not damage or have any adverse effect on the use of samples. No damage is foreseen in the entire test process.
4. Zealchon analysis software
Application fields: - Nondestructive, rapid and accurate analysis of alloy elements and alloy grade identification on the site - Metal identification /scrap metal sorting - QA/QC management in metal production, processing, casting, etc - Medicine and biological medicine - Identification of positive materials, oil refining and petrochemical industry - Thermal power plant, hydroelectric power station, nuclear power plant - Accurate element analysis of raw material and PMI identification so as to meet production needs and ensure security of equipment and materials used in the process.
