Rhing Industry X-Ray Inspection Testing Machine For Shoes Needle Detector Food
Product description:
XIS-9000D is widely used for the detection of foreign objects in various foods, pharmaceuticals, beverages, etc. (for example: metal, stone, glass, bone, rubber, etc.). Not only that, but also the device can realize multi-point miss detection and shielding. Segment detection, liquid level height detection, high-speed rejection detection, remote remote control, integrated real-time management and other functions.
Based on intelligent image analysis technology, XIS-9000D can effectively detect tiny foreign objects in products such as metal, stone, glass, bone, rubber and so on. In the food, medicine, beverage and other industries, food safety management HACCP and product quality have been widely used and have established a good reputation with excellent performance.
Applicable products: special models for glass bottles (detecting bottom glass fragments).
Product specification:
| Model | XIS-9000D |
| Optimum detection accuracy | plumbum:φ0.2mm,stainless steel ball:φ0.4mm,ceramic ball:φ0.8mm, bone:φ0.8mm,glass:φ1.0mm |
| Detection size parameter | Maximum detection width :100mm |
| Maximum detection height :300mm | |
| passing the largest size | 350*310mm(width*height) |
| The width of conveyor belt | 85mm(can be customized ) |
| The height from conveyor belt to guound | 1100±30mm |
| The speed of conveyor | 10-100m/min |
| Bearing capacity | 10Kg |
| X-ray output | 40-80kVp/0.2-5mA |
| X-ray leak | <3μSv/h(<International regulations 10μSv/h) |
| Detector type | Linear scan |
| Direction of scan | Double viewing angle |
| Pixel size | 0.4mm |
| displayer | 15”LCD touch screen |
| Operation type | Operation with touch screen |
| system | Windows 7 |
| Support data interface | USB |
| Parameter setting | self-learning&manual adjustment |
| Casing material | SUS304 |
| Conveyor belt matetial | PU |
| Air conditioner | internal recycle industrial air conditioner, automatic temperature control |
| Protecting type | Detachable protecting curtain |
| Clean way | tool-free detachable conveyor belt ,easy to clean |
| Power | AC220/230V,50/60Hz |
| Work environment | temperature:5-35℃/humidity:30-85%RH(no condensation) |
| Machine size | 3500*1300*1795mm(length*width*height) |
| Machine weight | 700Kg |
1. Comprehensive testing: It can detect large foreign objects such as metal, non-metal, etc., such as: metal, glass, stone, bone, ceramic, hard rubber, hard plastic, etc.; product properties are widely applicable, such as: plastic packaging, aluminum foil Packaging, glass filling, metal canning, bulk material testing, etc.
2, high-speed detection: the world's leading computing processing capacity, up to 120 m / min detection speed, greatly meet the production efficiency.
3, excellent detection accuracy, to ensure product quality and protect the reputation of the user brand.
4, rich expansion features: multi-point omission detection, defect detection (product defects, packaging defects) shield segmentation detection, liquid level detection, high-speed rejection detection, remote remote control, integrated real-time management and other functions.
5, easy to operate: 15-inch touch screen operation, self-learning function, intuitive and simple operating experience. Automatically save detection images for easy tracking.
6, green design concept: all accessories are in line with food requirements, the amount of radiation leakage meets the US, EU CE standards.
